OpenStack Swift is an open source cloud storage platform, which can be used to build massively scalable and highly robust storage clouds. There are two key use cases of Swift:
- A service provider offering cloud storage with a well defined RESTful HTTP API - i.e. a Public Storage Cloud. An ecosystem of applications integrated with that API are offered to the service provider’s customers. Service provider may also choose to only offer a select service (e.g. Cloud Backup) and not offer access to the API directly.
- A large enterprise building a cloud storage platform for use for internal applications - i.e. a Private Storage Cloud. The organization may do this because it is reluctant to send its data to a third party public cloud provider or to build a cloud storage platform which is closer to the users of its applications.
In both of above cases, as you plan to build your cloud storage infrastructure, you will face one of these three problems:
- Optimize my cost: You know how much usable storage capacity you need from your cloud storage, and you know how much aggregate throughput you need for applications using the cloud storage, but you want to know what is the least amount of budget you need to be able to achieve your capacity and throughput goals.
- Optimize my capacity: You know how much aggregate throughput you need for applications using the cloud storage, and you know your budget constraints, but you want to know the maximum capacity you can get for your throughput needs and budget constraints.
- Optimize my performance: You know how much usable storage capacity you need from your cloud storage, and you know your budget constraints, but you need to know the configuration to get best aggregate throughput for your capacity and budget constraints.
Solving any of the three problems above is very complex because of the myriad choices that the cloud storage builder has to make, e.g. size and number of various types of servers, network connectivity, SLAs etc. We have done extensive work in our labs and with several cloud providers to understand above problems and to address them with rigorous analysis. In this series of blogs we will provide some of the results of our findings as well as description of tools and services which can help you to build, deploy and maintain your storage cloud with confidence.
Definitions Since the terms used can be interpreted differently depending on context, below are the specific definitions used in this series of blogs for the three key parameters:
Capacity: It is the usable storage capacity, i.e. the size of the maximum application data that can be stored on the cloud storage. Usually, for better availability and durability, the data is replicated in the cloud storage across multiple systems. So, the the raw capacity of the cloud storage should be planned with the consideration of data redundancy. For example, in OpenStack Swift, each object is replicated three times by default. So, the total size of raw storage will be at least three times larger than the usable storage capacity.
Performance: It is the maximum aggregate throughput (MB/s or GB/s) that can be achieved by applications from the cloud storage. In this blog, we will also use the term throughput to denote aggregate throughput.
Cost: For this discussion we will only consider the initial purchase cost of the hardware for building the cloud storage. We expect that the built cloud storage will be put to use for several years, but we are not amortizing the cost over a period of time. We will point out best practices to reduce on-going maintenance and scaling costs. For this series of blogs we will use the terms “node” and “server” interchangeably. So, “storage node” is same as “storage server”.
Introducing the framework for the Swift Advisor
The Swift Advisor is a technique that takes two of the three constraints (Capacity, Performance, Cost) as inputs, and provides hardware recommendation as output, specifically count and configuration of systems for each type of node (storage and proxy) of the Swift storage cloud. This recommendation is optimized for the third constraint: e.g. minimize your budget, maximize your throughput, or maximize your usable storage capacity.
Before discussing the technical details of the Swift Advisor, let’s first look at a practical way to use the Swift Advisor: In order to build an optimized Swift cloud storage (Swift Cloud), an important feature of Swift Advisor is to consider a very large range of hardware configurations (e.g. a wide variety of CPU, memory, disk and network choices). However, it is unrealistic and very expensive to blindly purchase a large amount of physical hardware upfront and let Swift Advisor evaluate their individual performances as well as the overall performance after putting them together. Therefore, we choose to leverage virtualized and elastic environment offered by Amazon EC2 and build an optimized Swift Cloud on the EC2 instances initially.
While it may seem ironical that we are using a public compute cloud to come up with an optimized private storage cloud, the reasons for choosing EC2 as the test-bed for Swift Advisor are multi-fold: (1) EC2 provides many types of EC2 instances with different capacities of CPU, memory and I/O to meet the various needs. So, the Swift Advisor can try out many types of EC2 instances on the basis of pay-per-use, instead of physically owning the wide variety of hardware needed. (2) EC2 has a well defined pricing structure.
This provides a good comparison point for the cloud storage builders - they can look at the pricing information and justify the cost of owning their own cloud storage in the long run. (3) Specification of each type of EC2 instance, including CPU, memory, disk and network is well defined. Once an optimized Swift Cloud is built on the EC2 instances with the input constraints, the specifications of those EC2 instances can effectively guide the purchases of physical servers to build a Swift Cloud running on the physical hardware. In summary, you can use the elasticity of a compute cloud along with Swift Advisor to get specifications for your physical hardware based storage cloud, while preserving your desired constraints.
The high-level workflow of the Swift Advisor is shown below:
There are four important phases and we explain them as follows:
Sampling Phase: Our eventual goal is to build an optimized Swift cloud consisting of quantity A of proxy servers and quantity B of storage severs - A and B are unknown initially and we denote it as A:B Swift Cloud. In this first phase we focus on performance and cost characteristics of 1:N Swift Cloud. We look for the “magic” value of N that makes a 1:N Swift Cloud with the lowest cost per throughput ($ per MB/s) . The reason why we want to find a 1:N Swift cloud with the lowest $ per MB/s is to remove two potential pitfalls when building a Swift cloud : (1) Under-provisioning: the proxy server is under utilized and can still be attached to more storage servers to improve the throughput. (2) Over-provisioning: the proxy server has been overwhelmed by too many storage servers.
Since the potential combinatorial space for storage and proxy node choices is potentially huge, we use several heuristics to prune the candidates during various phases of the Swift Advisor. For example we do not consider very low powered configuration (e.g. Micro Instances) for proxy nodes.
After the sampling phase, for each combination of EC2 instance sizes on proxy and storage servers, we know the “magic” value of N that produces the lowest $ per MB/s of running a 1:N Swift cloud. You can run the sampling phase on any available virtual or physical hardware, but the larger the sample set the better.
Profiling Phase: Given the “magic” values of N from the sampling phase, our goal in this phase is to profile throughput curves (the throughput verses the size of Swift cloud) of several Swift clouds consisting of c proxy server and cN storage servers (c:cN Swift Cloud) with various values of c.
Please note that each throughput curve corresponds to each combination of hardware configuration (EC2 instance sizes in our case) of the proxy and storage servers. In our experiments, for each combination of EC2 instance sizes of the proxy and storage servers, the profiling starts from 2:2N Swift Cloud and we double the number of proxy and storage servers each time. (e.g. 4:4N, 8:8*N, ….). All cN EC2 instances for storage nodes are identical.
The profiling stops when the throughput of c:cN Swift Cloud is larger than the throughput constraint. After that, we apply a non-linear or linear regression on the profiled throughputs to plot a throughput curve with the X-values of c and Y-values of the throughput. The output of the profiling phase is a set of throughput curves of c:cN Swift Cloud, where each curve corresponds to a combination of EC2 instance sizes of the proxy and storage servers.
Optimization Phase: By taking the throughput curves from the profiling phase and two input constraints, the optimization phase is where we figure out a Swift Cloud optimized for the third parameter. We do this by plotting constraints on each throughput curve and look for the optimized value across all curves.
For example, lets say we are trying to optimize capacity with maximum budget given and minimum throughput requirement: we will input the minimum required throughput on each throughput curve and find the corresponding values of c, and then reject the throughput curves where the implied hardware cost is more than the budget. Out of the remaining curves we will select the one resulting in maximum capacity based on cN * storage capacity of the system used for storage server.
Validation and Refinement Phase: The validation phase checks if the optimized Swift cloud really conforms to the throughput constraint through a test run of the workloads. If the test run fails a constraint, then the Swift Advisor goes to the refinement phase. The refinement phase gets the average throughput measured from the test run and sends it to the profiling phase.
The profiling phase adds that information to the profiled data to refine the throughput curves. After that, we use the refined throughput curves as the inputs to redo the optimization phase. The above four phases consists of the core of Swift Advisor. However, there are some important remaining issues to be discussed:
(1) choice of the load balancer
(2) mapping between the EC2 instance and the physical hardware when the cloud operators finally want to move the optimized Swift Cloud to physical servers, while preserving the three constraints on the new hosting hardware.
(3) SLA constraints. We will address these and other issues in building an optimized storage cloud for your needs in our future blogs.
Some Sampling Observations
In this blog, we present some of the results based on running Sampling phase on a selected configuration of systems. In future blogs, we will post the results for Profiling phase and Optimization phase.
For our sampling phase, we assume the following potential servers are available to us for proxy node: EC2 Large (Large), EC2 Extra Large (XL), EC2 Extra Large CPU-high (CPU XL) and EC2 Quadruple Extra Large (Quad). While the candidates for storage node are: EC2 Micro (Micro), EC2 Small (Small) and EC2 Medium (Medium).
Therefore, the total number of combinations of proxy and storage nodes is 4 * 3 =12 and we need to find the “magic” value of N that produces the lowest $ per MB/s of running a 1:N Swift cloud for each combination. We start the sampling for each combination from N=5, and increase it until the throughput of 1:N Swift Cloud stops increasing. Note that a production Swift Cloud implementation requires at least 5 storage nodes. This happens when the proxy node is fully loaded and adding more storage nodes can not improve the throughput anymore.
We use Amanda Enterprise as our application to backup a 10G data file to the 1:N Swift cloud. The Amanda Enterprise runs on an EC2 Quad instance to ensure that one Amanda Enterprise server can fully load the 1:N Swift cloud in all cases. For this analysis we are assuming that the cloud builder is building the cloud storage optimized for backup operations. The user of the Swift Advisor should change the test workload based on the desired mix of expected application workload when the cloud storage goes production. We first look at the throughput for different values of N on each combination of EC2 instance sizes on proxy and storage nodes.
(1) Proxy node runs on EC2 Large instance and the three curves are for the three different sizes for the storage node:
Observations with EC2 Large Instance based Proxy Node:
- Micro Instance based Storage nodes: Throughput stops increasing at # storage node = 30
- Small Instance based Storage nodes: Throughput stops increasing at # storage node = 10
- Medium Instance based Storage nodes: Throughput stops increasing at # storage node = 5
(2) Proxy node runs on EC2 XL instance:
Observations with EC2 XL Instance based Proxy Node:
- Micro Instance based Storage nodes: Throughput stops increasing at # storage node = 30
- Small Instance based Storage nodes: Throughput stops increasing at # storage node = 10
- Medium Instance based Storage nodes: Throughput stops increasing at # storage node = 5
(3) Proxy node runs on EC2 CPU XL instance:
Observations with EC2 CPU XL Instance based Proxy Node:
- Micro Instance based Storage nodes: Throughput stops increasing at # storage node = 30
- Small Instance based Storage nodes: Throughput stops increasing at # storage node = 10
- Medium Instance based Storage nodes: Throughput stops increasing at # storage node = 5
(4) Proxy node runs on EC2 Quad instance:
Observations with EC2 Quad Instance based Proxy Node:
- Micro Instance based Storage nodes: Throughput stops increasing at # storage node = 60
- Small Instance based Storage nodes: Throughput stops increasing at # storage node = 20
- Medium Instance based Storage nodes: Throughput stops increasing at # storage node = 10
Looking at above graphs, we can already draw some conclusions: E.g. if the only storage nodes available to you were equivalent to EC2 Micro Instance and you wanted your storage cloud to be able to scale beyond 30 storage nodes (per proxy node), you should pick at least EC2 Quad Instance equivalent proxy node. Let’s look at the figures (1) - (4) from another view: fix the EC2 instance size of storage node and vary the EC2 instance size of proxy node
(5) Storage node runs on EC2 Micro instance and the four curves are for the four different EC2 instance sizes on proxy node:
Observations with EC2 Micro Instance based Storage Node:
- Large Instance based Proxy nodes: Throughput stops increasing at # storage node = 30
- XL Instance based Proxy nodes: Throughput stops increasing at # storage node = 30
- CPU XL Instance based Proxy nodes: Throughput stops increasing at # storage node = 30
- Quad Instance based Proxy nodes: Throughput stops increasing at # storage node = 60
From the above graphs, we can conclude that, (a) when proxy node runs on the Quad instance, it has the capability, especially the network bandwidth, that can accommodate more storage nodes and achieve higher throughput (MB/s) than using other instances for the proxy node. (b) Different EC2 instance sizes on storage node load the same proxy node at different speed: for example, when proxy node runs on the Quad instance, we need to use 60 Micro instances as storage nodes to fully load the proxy node.
While, if we use Small or Medium instance size on storage node, we only need 10 storage nodes to fully load the proxy node. Based on the above results on throughput, now we look at the $ per throughput (MB/s) for different values of N on each combination of EC2 instance sizes on proxy and storage nodes. Here, $ is defined as the EC2 usage cost of running 1:N Swift cloud for 30 days. In this blog we are only showing numbers with proxy node set to EC2 Quad Instance. We will publish numbers for other combinations in another detailed report.
(6) Proxy node runs on EC2 CPU Quad instance:
Observations with EC2 Quad Instance based Proxy Node:
- Micro Instance based Storage nodes: The lowest $ per MB/s is achieved at # storage node = 60
- Small Instance based Storage nodes: The lowest $ per MB/s is achieved at # storage node = 15
- Medium Instance based Storage nodes: The lowest $ per MB/s is achieved at # storage node = 5
Overall, the lowest $ per MB/s in the above figure is achieved by using Medium Instance based Storage nodes at # storage node = 5 This specific result will provide input to the profiling phase of N=5, 15 and 60 for proxy/storage node combination EC2 Quad/Medium, EC2 Quad/Small and EC2 Quad/Micro respectively.
So, one can conclude that when using 1 Quad Instance based Proxy node it may be better to use 5 Medium based Storage nodes to achieve the lowest $ per MB/s, rather than using more Micro Instance based storage nodes. Above graphs are a small subset of the overall performance numbers achieved during the Sampling phase.
The overall objective here is to give you a summary of our recommended approach to building an optimized Swift Cloud. As mentioned above, we will publishing detailed results in another report, as more conclusions and best practices in future blogs in this series.
If you are thinking of putting together a storage cloud, we would love to discuss your challenges and share our observations. Please drop us a note at swift@zmanda.com
